Yedek Parça Listesi

List of Materials

code description quantity price pieces weight volume
03205 END CAP Swivel foot pad for d. 42 mm pipe. Angle can be adjusted by rotating the eye ball socket. Price per pair 1 49.44
0111PX10 PUMPEX - FRONT PUMP BODY 1 60.00
0111PX14 PUMPEX - DIFFUSER 1 40.00
0111PX17 PUMPEX - MECHANICAL SEAL COMPLETE 2 26.00
8500423 IMBUS CİVATA M10X20 1 1.42
0111PX25 PUMPEX - PUMP LEG 1 40.00
0111PX26 PUMPEX RUBBER FOOT PUMP SUPPORT FOR 1 3.60
860124 PUMPEX - DİFÜZÖR CONTASI (VİTON) 70X6 1 50.00
0111PXE02 PUMPEX - BODY O-RING (VİTON) 264X250X7 1 100.00
0111STR02 DRAIN PLUG 1 1.70
860285 O-RING FOR DRAIN PLUG 2 0.40
0111STR37N COUNTER SCREW İNOX 1 0.70
8500409 INOKS CİVATA M8X40 1 1.50
8500073 M8 HEXAGON HEAD BRASS NUT 934 1 3.06
8500248 M8 Stamp 4
8500399 M8X70 INOX SCREW 2 3.00
0111PX1603 PUMPEX IMPEILER 1,5 HP 1 40.00
0111PX41 PUMPEX - POMPA ARKA GÖVDESİ (80 GÖVDE) 1
