GEMAS “NEPTUNE” SAND FILTERS
GEMAS “NEPTUNE” SAND FILTERS
Filter shell made of fiberglass reinforced laminated polyester, including pressure gauge, side or top-mounted multiport valve and air purge. Screwed lid with handle facilitates easy access, Test pressure 3,5 kg/cm2. Max. operation pressure 2,5 kg/cm2. Bed depth: 0,80 m. Filtration rate: 50 m3 /h / m2.
| descripción | código de almacenamiento | precio (€) |
peso (kg) |
volumen (m³) |
PİEZAS DE REPUESTO
|
|---|---|---|---|---|---|
| Ø450 mm - 1,5" multiport side valve - 8 m³/h | 021211 | Regístrese para ver el precio | 14.400 | 0.145 | Analizar |
| Ø500 mm - 1,5" multiport side valve - 10 m³/h | 021212 | Regístrese para ver el precio | 15.550 | 0.215 | Analizar |
| Ø650 mm - 1,5" multiport side valve - 17 m³/h | 021213 | Regístrese para ver el precio | 22.500 | 0.325 | Analizar |
| Ø800 mm - 2” multiport side valve - 25 m³/h | 021214 | Regístrese para ver el precio | 37.600 | 0.665 | Analizar |
| Ø950 mm - 2” multiport side valve - 35 m³/h | 021215 | Regístrese para ver el precio | 50.500 | 0.905 | Analizar |
